Industrial circular connectors

Industrial circular connectors are heavy-duty connectors with a cylindrical shape and a round mating face. They are typically used in harsh environments such as automating processes, industrial environments and railway applications.

Industrial circular connectors feature multiple contacts, typically housed in a plastic or metal body. Some of HARTING's circular connectors ensure high IP protection ratings such as IP67, IP68 and IP69K, making them ideal to design into high humidity environments.

A complete industrial circular connector consists of the following individual components:

Backshell

• Various options for cable outlets

Insert

• Broad range of inserts along the lifelines (data, signal, power)

Plug

• Bayonet locking

Receptacles

• Jam-Nut

• Wall-Mount

• Cable-to-Cable

Insert

• Broad range of inserts along the lifelines (data, signal, power)

Backshell

• Various options for cable outlets

• Fixing-Nut

Need to find the right interfaces for your machine construction quickly and reliably without the drawn-out process of considering the connector details and all the many combination options? The Circular Connector Configurator will quickly put all the necessary information and data relevant to your decision making at your fingertips. Start directly with your first configuration!

Your benefits at a glance:

• A guided configuration – just a few steps to your finished complete connector solution

• Enables the simple compilation of a customised solution from a complex portfolio

• Prepares all necessary design-in data and documents

• Detailed 3D live visualisation for a visual check

• Reduced complexity and error prevention ensures safety and time savings

• Collaboration made easy with simple sharing of the configuration ID

• Access to all configurations in your personal account
